DC1101 SERIES · RF + ZigBee
DC1101Z
8–36 V DC On/Off Receiver.
DC-powered on/off control. Confirm your supply, connected load and installation requirements.
Control technology
Confirm the connected load and the complete system before ordering.
Compare receiver models ↗MODEL SPECIFICATIONS
The details that matter.
| Model | DC1101Z |
|---|---|
| Series | DC1101 Series |
| Control solution | RF + ZigBee |
| Dimensions (L × W × H) | 44 × 44 × 22 mm |
| Input | 8–36 V DC |
| Rated current | 5A |
| Load power | Contact us to confirm |
| Frequency | RF 433MHz + Zigbee 2.4GHz |
| Certifications and standards | EuropeIEC 62368-1:2014; EN 62368-1:2014+A11:2017EN IEC 62311:2020EN 301 489-1/-3/-17; EN 55032/55035; EN IEC 61000-3-2; EN 61000-3-32014/53/EUETSI EN 300 220-1 V3.1.1; EN 300 220-2 V3.2.12014/35/EU; EN 62368-1:2014+A11:20172011/65/EU; (EU) 2015/863; IEC 62321 series North AmericaTested samples passed CSA/UL 62368-1:2019 requirements (NTEK third-party laboratory). United KingdomBS EN IEC 62368-1:2020+A11:2020UK Radio Equipment Regulations 2017BS EN 62479:2010ETSI EN 300 220-1 V3.1.1; EN 300 220-2 V3.2.1ETSI EN 301 489-1 V2.2.3 References from linked documentation. Model mapping and current configuration applicability remain under review. |
Fields marked “Contact us to confirm” are not yet available in the product record.
